Scarlet ST-15D Class 1 Sound Analyzer
In stock

Scarlet ST-15D Class 1 Sound Analyzer

SKU : SCST15D
MAKE : SCARLET
MODEL : ST-15D
AVAILABILITY : IN STOCK
Scarlet
SAR 12,300.00 - SAR 12,300.00
SAR 12,300.00
SAR 12,300.00 - SAR 12,300.00
SAR 12,300.00
(Including VAT)

Scarlet ST-15D Class 1 Sound Analyzer

The Scarlet ST-15D Class 1 Sound Analyzer is a high-performance sound measurement instrument designed for occupational, industrial, and environmental noise analysis. Complying with IEC 61672 Class 1 standards, it delivers precise sound level measurements with advanced 1/3 octave band analysis, GPS positioning, statistical analysis, and optional audio recording. It is ideal for professional noise surveys, environmental monitoring, and workplace noise assessments.

Features

  • IEC 61672 Class 1 compliant
  • 20–142 dB measurement range (145 dB Peak)
  • 10 Hz–20 kHz frequency range
  • ±0.7 dB high accuracy
  • Real-time 1/3 octave band analysis
  • Built-in GPS analyzer
  • Statistical noise analysis
  • USB & RS232 data interface
  • 240 × 320 full-color display
  • Up to 24-hour battery life
  • ScarletSound PC software support
  • Optional audio recording, FFT, dosimeter & 1/1 octave analysis

Standards

IEC 61672 Class 1, IEC 61260 Class 1, IEC 61252:2002

Microphone

1/2-inch pre-polarized condenser

Frequency Range

10 Hz–20 kHz

Measurement Range

20–142 dB (145 dB Peak)

Accuracy

±0.7 dB

Self-generated Noise

<12 dB(A), <17 dB(C), <22 dB(Z)

Frequency Weighting

A, C, Z, B, D

Time Weighting

Fast, Slow, Impulse, Peak

Display

240 × 320 color LCD

Resolution

0.1 dB

Sampling Frequency

48 kHz

Data Storage

32 MB Flash RAM, optional SD card

Output Interface

USB, RS232, AC, DC

Power Supply

4 × LR6 batteries or 5 V external power

Battery Life

Up to 30 hours

Dimensions

260 × 80 × 30 mm

Weight

0.35 kg

Operating Temperature

-10°C to +50°C

ST-15D Datasheet : Download

1. What is the ST-15D used for?
It is used for professional occupational and environmental noise analysis.

2. Which standard does it comply with?
IEC 61672 Class 1.

3. What is the measurement range?
20 to 142 dB (145 dB Peak).

4. Does it support octave band analysis?
Yes, it supports real-time 1/3 octave band analysis, with optional 1/1 octave analysis.

5. Does it include GPS?
Yes, it has a built-in GPS analyzer for location-based noise measurements.

6. Can data be transferred to a PC?
Yes, via USB using ScarletSound software.

7. Can it record audio?
Yes, optional WAV audio recording is available.

8. Which applications is the ST-15D suitable for?
Industrial, environmental, construction, transportation, airport, and workplace noise monitoring.
