SC300-A Intelligent thermal camera
In stock

SC300-A Intelligent thermal camera

SKU : HKSC300A
MAKE : HKDQTECH
MODEL : SC300-A
AVAILABILITY : IN STOCK
Hkdqtech
SAR 9,900.00 - SAR 9,900.00
SAR 9,900.00
SAR 9,900.00 - SAR 9,900.00
SAR 9,900.00
(Including VAT)

SC300-A Intelligent thermal camera

HKDQTECH SC300-A Intelligent Thermal Camera is a professional-grade handheld infrared thermal imaging camera designed for industrial inspection, electrical maintenance, power systems, and predictive maintenance applications. It combines high-resolution thermal imaging, accurate temperature measurement, intelligent analysis functions, and multiple communication options for efficient fault detection.

The SC300-A uses an uncooled FPA infrared detector with VOX/amorphous silicon technology and provides 384 × 288 infrared resolution with high thermal sensitivity (NETD <40 mK) to detect small temperature differences. It supports manual focus and interchangeable lenses for different inspection distances and applications.

 Features

  • High IR resolution
  • Manual focus
  • <40mK thermal sensitivity with 24° lens
  • Accuracy: ±3.6°F or ±2%
  • Multiple-lenses Available
  • IP54 protection

MODEL

SC300-A

Detector type

Uncooled FPA, Amorphous silicon or VOX material

IR Resolution

384x288

Thermal Sensitivity/NETD

＜40mK（@30℃）

Spectral Range

7.5~14μm

Standard lens

24

Optional lens

48 °, 12 °, 6 °, etc

Spatial resolution (IFOV)

1.30mrad (24° lens); 2.26mrad (48° lens); 0.68mrad (12° lens); 0.34mrad (6° lens

Focus

Manual

Minimum focal distance

0.15m (24° lens); 0.15m (48° lens); 0.5m (12° lens); 1m (6°

Display

4.3"/5" Sunshine Visible Display screen, 480*272/800*480

Object temperature range

-20℃~+150℃ (low temperature range)/0℃~+410℃ (medium temperature range)

Optional temperature range

+300°C~+650°C/+300°C~+2,000°C/other ranges (high temperature range)

Temperature measurement accuracy

±2℃ or ±2% of readings

Digital camera

Built-in 500W pixel digital camera with LED light

Laser pointer

Support

Palette

10 color palettes

Touch screen

Capacitive touch screen

Bluetooth

Support Bluetooth headset playback

WIFI

Support,support preview SD card pictures through WIFI

4G (optional)

Transmit real-time images to mobile phones via 4G, view cloud images

Temperature measurement settings

10 points, 10 boxes, 5 lines at the same time, including maximum/minimum/average values

Full screen maximum/minimum temperature

Support, automatically capture the highest/lowest temperature of the full screen

Digital zoom

1×, 2×, 4×, 8×

Radiance correction

Automatic, based on input values of emissivity

Atmospheric transfer correction

Automatic, based on input values of distance, atmospheric temperature and relative humidity

Isotherms

Support

Storage method

32G high-speed SD card

Infrared image format

.jpg (including full temperature data)/.png (including full temperature data)

Visible light image format

.jpg

Video output

HDMI

Video output interface

Micro HDMI interface

Battery type

Removable rechargeable lithium battery

Power supply voltage

DC12V

Battery operating time

General use>3 hours at 25℃

Charging method

Double-bay charger or car charger

Weight

1.09kg (including battery)

Dimensions

260x135x136mm

Operation temperature

-20°C~55°C

Storage temperature

-40°C~70°C

Humidity (operating and storage)

≤95%, non-condensing

Packaging level

IP54

SC-A Series Datasheet : Download

1. What is the HKDQTECH SC300-A?
A professional intelligent handheld thermal camera for industrial inspections.

2. What is the infrared resolution?
384 × 288 pixels.

3. What is the thermal sensitivity (NETD)?
Less than 40 mK (@30°C).

4. What temperature range does it measure?
-20°C to 410°C standard, with optional ranges up to 2000°C.

5. How accurate is the temperature measurement?
±2°C or ±2% of the reading.

6. Does it have a visible-light camera?
Yes, it features a built-in 5 MP digital camera with LED light.

7. Does it support image and video recording?
Yes, it captures thermal images and H.264 infrared videos.

8. Does it support Wi-Fi and Bluetooth?
Yes, it supports Wi-Fi and Bluetooth connectivity.

SC300-A Intelligent thermal camera

HKDQTECH SC300-A Intelligent Thermal Camera is a professional-grade handheld infrared thermal imaging camera designed for industrial inspection, electrical maintenance, power systems, and predictive maintenance applications. It combines high-resolution thermal imaging, accurate temperature measurement, intelligent analysis functions, and multiple communication options for efficient fault detection.

The SC300-A uses an uncooled FPA infrared detector with VOX/amorphous silicon technology and provides 384 × 288 infrared resolution with high thermal sensitivity (NETD <40 mK) to detect small temperature differences. It supports manual focus and interchangeable lenses for different inspection distances and applications.

 Features

  • High IR resolution
  • Manual focus
  • <40mK thermal sensitivity with 24° lens
  • Accuracy: ±3.6°F or ±2%
  • Multiple-lenses Available
  • IP54 protection

MODEL

SC300-A

Detector type

Uncooled FPA, Amorphous silicon or VOX material

IR Resolution

384x288

Thermal Sensitivity/NETD

＜40mK（@30℃）

Spectral Range

7.5~14μm

Standard lens

24

Optional lens

48 °, 12 °, 6 °, etc

Spatial resolution (IFOV)

1.30mrad (24° lens); 2.26mrad (48° lens); 0.68mrad (12° lens); 0.34mrad (6° lens

Focus

Manual

Minimum focal distance

0.15m (24° lens); 0.15m (48° lens); 0.5m (12° lens); 1m (6°

Display

4.3"/5" Sunshine Visible Display screen, 480*272/800*480

Object temperature range

-20℃~+150℃ (low temperature range)/0℃~+410℃ (medium temperature range)

Optional temperature range

+300°C~+650°C/+300°C~+2,000°C/other ranges (high temperature range)

Temperature measurement accuracy

±2℃ or ±2% of readings

Digital camera

Built-in 500W pixel digital camera with LED light

Laser pointer

Support

Palette

10 color palettes

Touch screen

Capacitive touch screen

Bluetooth

Support Bluetooth headset playback

WIFI

Support,support preview SD card pictures through WIFI

4G (optional)

Transmit real-time images to mobile phones via 4G, view cloud images

Temperature measurement settings

10 points, 10 boxes, 5 lines at the same time, including maximum/minimum/average values

Full screen maximum/minimum temperature

Support, automatically capture the highest/lowest temperature of the full screen

Digital zoom

1×, 2×, 4×, 8×

Radiance correction

Automatic, based on input values of emissivity

Atmospheric transfer correction

Automatic, based on input values of distance, atmospheric temperature and relative humidity

Isotherms

Support

Storage method

32G high-speed SD card

Infrared image format

.jpg (including full temperature data)/.png (including full temperature data)

Visible light image format

.jpg

Video output

HDMI

Video output interface

Micro HDMI interface

Battery type

Removable rechargeable lithium battery

Power supply voltage

DC12V

Battery operating time

General use>3 hours at 25℃

Charging method

Double-bay charger or car charger

Weight

1.09kg (including battery)

Dimensions

260x135x136mm

Operation temperature

-20°C~55°C

Storage temperature

-40°C~70°C

Humidity (operating and storage)

≤95%, non-condensing

Packaging level

IP54

SC-A Series Datasheet : Download

1. What is the HKDQTECH SC300-A?
A professional intelligent handheld thermal camera for industrial inspections.

2. What is the infrared resolution?
384 × 288 pixels.

3. What is the thermal sensitivity (NETD)?
Less than 40 mK (@30°C).

4. What temperature range does it measure?
-20°C to 410°C standard, with optional ranges up to 2000°C.

5. How accurate is the temperature measurement?
±2°C or ±2% of the reading.

6. Does it have a visible-light camera?
Yes, it features a built-in 5 MP digital camera with LED light.

7. Does it support image and video recording?
Yes, it captures thermal images and H.264 infrared videos.

8. Does it support Wi-Fi and Bluetooth?
Yes, it supports Wi-Fi and Bluetooth connectivity.
